Opto-Matic Oiler - Plastic

Opto-Matic oilers provide a constant level of oil in a pump bearing housing, gear box, or other oil sump applications. Throughout processing industries, the Opto-Matic oiler is the industry standard. Different reservoir capacities allow for use in many applications.

Contact Us to Purchase

Feature

Large Surge Chamber

LS, EH, and EHB models have a large surge chamber to minimize potential of leakage during oil surge conditions.

Feature

Air Vent Slots

The air vent slots permit air to enter the oiler for proper functioning at all times. The air vents are equally spaced around the oiler. The chances of all the air vents becoming clogged is almost impossible compared to oilers with a single vent hole.

Additional Features

Durable

A high strength, transparent, and ribbed plastic reservoir provides long life and impact resistance.

Adjustability

Adjustable level setting allows use in many applications

Side and Bottom Connections

EB, EHB, and LS models provide side and bottom connections for simplified installation

Other Specs

Model Description Style Capacity Connection (NPT) Dim A (in) Dim B (min) Dim B (max) Dim C (min)
30024 Opto-Matic Type LS 4 oz 1/4 2-5/16 5-7/16 6-3/16 9/32
30028 Opto-Matic Type LS 8 oz 1/4 2-5/8 6-9/16 7-5/16 9/32
30052 Opto-Matic Type E 2 oz 1/4 1-15/16 3-7/8 4-3/8 1/4
30054 Opto-Matic Type E 4 oz 1/4 2-5/16 4-9/16 5-1/16 1/4
30058 Opto-Matic Type E 8 oz 1/4 2-5/8 5-11/16 6-3/16 1/4
30062 Opto-Matic Type EB 2 oz 1/4 1-15/16 3-7/8 4-3/8 1/4
30064 Opto-Matic Type EB 4 oz 1/4 2-5/16 4-9/16 5-1/16 1/4
30068 Opto-Matic Type EB 8 oz 1/4 2-5/8 5-11/16 6-3/16 1/4
30074 Opto-Matic Type EH 4 oz 1/4 2-5/16 5-11/16 6-3/16 1/4
30078 Opto-Matic Type EH 8 oz 1/4 2-5/8 6-13/16 7-5/16 1/4
30082 Opto-Matic Type EHB 2 oz 1/4 1-15/16 5 5-1/2 1/4
30084 Opto-Matic Type EHB 4 oz 1/4 2-5/16 5-11/16 6-3/16 1/4
30088 Opto-Matic Type EHB 8 oz 1/4 2-5/8 6-13/16 7-5/16 1/4
